Series	A180SS
Material	Brass
Brand	AIGO
Item Dimensions LxWxH	(1/4") 4.29 x 1.48 x 2.12 inches
	(3/8") 4.29 x 1.48 x 2.12 inches
	(1/2") 1.41 x 1.72 x 2.28 inches
	(3/4") 5.61 x 2.1 x 2.77 inches
	(1") 5.85 x 2.53 x 3.1 inches
Exterior Finish	Forged Brass
Connection Type	Female NPT x Female NPT x Female NPT
Maximum Working Pressure	400 PSI WOG / 150 PSI SWP
Temperatures range	-40 to 302 F

About this item

• Full port design; Easy-to-turn solid handle
• L-Port design (please refer to the image)
• Adjustable packing gland; Blowout proof stem
• Constructed from forged brass for a greater structural integrity and mechanical strength than barstock
• Use with brass, steel, iron and stainless steel pipe
• Teflon tape and thread sealant are recommended for threaded joints
• Designed for use in air, water, oil, nature, manufactured, mixed, liquefied petroleum or propane and LP Gas-Air
• CSA approved manually operated gas valve for use in house piping system, appliances, appliance connector valves and hose end valves
• Conform to specifications ASTM (American Society for Testing and Materials) B124 and B16
• NPT threads meet ASME B1.20.1
• Has hex surfaces making it easier to apply wrenches during installation
• This valve contain low-lead, no more than 2.5%.
